Three-phase power supply for DIN rail 960W 48V TDR-960-48


MEAN WELL company

MEAN WELL is a renowned, global brand specializing in the design and production of switching power supplies, which has been enjoying the trust of customers around the world for years. Founded in 1982 in Taiwan, MEAN WELL has earned a reputation as one of the leading manufacturers of reliable power supplies, offering a wide range of products with high quality, performance and competitive prices.


Power Supply Description:

Power Supply MEAN WELL TDR-960-48 is a three-phase DIN rail power supply with a power of 960W, which can be powered from three or two phases. It is characterized by very high efficiency up to 94.5%. This device is equipped with a built-in active PFC function, short circuit, overload, overvoltage and thermal protection. Additionally, the power supply has an LED indicator and a DC OK relay connector. The possibility of parallel operation of up to four devices and cooling in open air circulation make it a reliable and effective solution for demanding industrial applications.


Description of the TDR series:

TDR series of power supplies by MEAN WELL is a modern solution for industry, offering three-phase or two-phase power supply with a wide input voltage range from 340 to 550 VAC. They are characterized by high energy efficiency of 94% and the ability to adjust the output voltage. These power supplies are equipped with protection against overload, overvoltage, short circuits and overheating, which ensures their reliability and safety of use. Additionally, the TDR series has safety certificates and meets EMC standards, making them an ideal choice for industrial applications.


Main features of the power supply:

• Three-phase 960W DIN rail power supply

• Possibility of power supply from 3 phases (or 2)

• Built-in active PFC function

• p>

• Efficiency up to 94.5%

• Possibility of parallel operation (3+1) up to 3840W

• Short circuit, overload, overvoltage, thermal protection

• LED operation indication

• DC OK relay connector

• p>

• Permissible load capacity 130% of peak power for 3 seconds

• Open air cooling

• Operating temperature -30~+70°C

• Mounting on DIN TS35 / 7.5 or 15 rail

• Compliance with a number of standards and certificates

• 3 years warranty.



Application:

Power supply TDR-960-48 from MEAN WELL is a three-phase DIN rail power supply that is widely used in industrial automation. Thanks to its high efficiency of up to 94.5% and the possibility of parallel operation, it is an ideal solution where reliability and efficiency are important. This power supply can provide a constant 48V output voltage that is adjustable by +/-10%, making it a universal tool for a variety of industries including machinery, telecommunications, LED lighting, alarm and control systems.


Specification:

Output voltage:	48V
Output power:	960W
MAX output current:	20A
Output voltage regulation:< /p>	48 ∼ 55V
Input voltage:	90 ~ 264VAC
Operating temperature:	-30 - +70º
Overload protection:	Yes (Hiccup)
Surge Protection:	Yes (Hold & Restart)
Safety certificates:	UL508, , EAC TP TC 004 approved, IEC62368-1 CB approved by SIQ; Design refer to BS EN/EN62368-1 AS/NZS62368.1
Model:	TDR-960-48
Dimensions:	110x125,2x150mm
Weight:	2470g

Warranty:

3 Years
