Three-phase power supply for DIN rail 480W 48V TDR-480-48


MEAN WELL company

MEAN WELL is a renowned, global brand specializing in the design and production of switching power supplies, which has been enjoying the trust of customers around the world for years. Founded in 1982 in Taiwan, MEAN WELL has earned a reputation as one of the leading manufacturers of reliable power supplies, offering a wide range of products with high quality, performance and competitive prices.


Power Supply Description:

Power Supply TDR-480-48 from MEAN WELL is a three-phase DIN rail power supply with a power of 480W, which can be powered from three or two phases. It has an output voltage of 48V at a current of 10A and is characterized by high efficiency of up to 92%. Its compact dimensions are 85.5mm wide, which makes it an ideal solution in places where space is limited. This power supply is also equipped with an active PFC function and short-circuit, overload, overvoltage and thermal protections, ensuring reliability and safety of use.


TDR series description:

The TDR series from MEAN WELL is advanced industrial power supplies that can be powered from both three and two phases. They are characterized by a wide input voltage range from 340 to 550 VAC, which allows them to be adapted to various network conditions. These power supplies are distinguished by the ability to adjust the output voltage and the operation signaling function, ensuring the stability and safety of the power supply. Their high energy efficiency, reaching 94%, contributes to the reduction of energy consumption and heat emissions. Additionally, the TDR series is equipped with protection against overload, overvoltage, short circuits and overheating, which guarantees long-term and reliable operation.


Main features of the power supply:

• < p>Power supply: 3-phase or 2-phase option

• Input voltage range: 340 - 550 VAC

• Possibility overload: up to 130% Active PFC (power factor): > 0.94

• Output voltage regulation: 48 ~ 55V

• Built-in current lock

• Protections: against overload, overvoltage, short circuits and overheating

• Efficiency: > 94%

• Operating temperature range: -30°C to +70°C

• Safety certificates: UL508, EAC TP TC 004 approved, IEC62368-1 CB approved by SIQ

• EMC standards: BS EN/EN55032 (CISPR32), BS EN/EN61204-3 Class B, BS EN/EN61000- 3-2,-3, EAC TP TC 020

• Dimensions: 85.5 x 125.2 x 128.5 mm

• Weight: 1.51 kg



Application:

The MEAN WELL TDR-480-48 power supply is a three-phase industrial power supply for a DIN rail, which is widely used in industrial automation . Thanks to its compact width of 85.5 mm and the possibility of power supply from three or two phases, it is an ideal solution where space efficiency and operational reliability are important. This power supply offers high efficiency up to 92%, built-in active PFC function and the ability to operate in a wide temperature range from -30 to +70°C, which makes it suitable for applications in difficult industrial conditions.


Specification:

Output voltage:	48V
Output power:	480W
MAX output current:	10A
Output voltage regulation:	48 ∼ 55V
Input voltage:	90 ~ 264VAC
Operating temperature:	-30 - +70º
Overload protection:	Yes (Hiccup)
Surge Protection:	Yes (Hold & Restart)
Safety certificates:	UL508, IEC62368-1 AS/NZS 62368.1, only for 2 , approved, ,UL 62368-1, BIS IS13252(Part1) ( 4V) EAC TP TC 004 Design refer to BS EN/EN62368-1
Model:	TDR-480-48
Dimensions:	85.5 x125.2x128.5mm
Weight:	1510g
Warranty:	3 Years
