DIN rail power supply 120W 12V SDR-120-12

MEAN WELL company

One of the most well-known and respected brands on the switching power supply market. MEAN WELL was founded in 1982 in Taiwan and has since then continuously provided high-quality products for various industries and applications. MEAN WELL offers a wide range of power supplies, including AC/DC, DC/DC, DC/AC, LED, medical, industrial, track and more. MEAN WELL is a leader in technological innovation and has many certificates and awards for its solutions. MEAN WELL is a brand that combines reliability, efficiency, safety and competitive price.


Description of the power supply:

The MEAN WELL SDR-120-12 power supply is an efficient device designed for mounting on DIN rail. It is characterized by an output voltage of 12V with a current of up to 10A and a power of 120W. It has a built-in active PFC function and efficiency of up to 91%, which ensures high power quality. Short-circuit, overload, overvoltage and thermal protections guarantee safe use. The power supply is designed to operate at temperatures from -25 to +70°C, which makes it reliable in various operating conditions.


Series description:

The MEAN WELL series of SDR power supplies is modern AC-DC devices designed for mounting on a DIN TS-35/7.5 or 15 rail. They are characterized by a metal housing, ultra-thin width and high efficiency up to 94%. These power supplies are equipped with active power factor correction (PFC), which ensures high power quality and meets EN61000-3-2 standards. The SDR series includes models ranging from 75 to 960 W, offering various output voltages, making them suitable for many industrial applications.


The main features of the SDR-120-12 power supply are:

• Type: Industrial DIN rail AC-DC power supply

• Output: 12Vdc at 10A

• < p>Output power: Maximum 120W

• Housing: Metal

• Width: Ultra slim, 40mm

• PFC Function: Built-in Active PFC Function, PF>0.93

• AC Input: Universal AC Input / Full Range

• Protections: Short circuit / Overload / Overvoltage / Overheating

• Safety certifications: Compliance with international safety certifications

Application:

The MEAN WELL SDR-120-12 power supply is a high-efficiency device designed for mounting on a DIN rail. It is used in a wide range of industrial applications such as automation, telecommunications, alarm systems, control, LED lighting, medicine, testing and measurement, and transportation. It features a metal housing, ultra-thin width and high efficiency of up to 94%, as well as built-in active power factor correction (PFC) function, which ensures high power quality.


Specification:

< tr>

Operating temperature:

-25 - +70 C
