Rated voltage:

450 V

Rated surge voltage:

4 kV

Rated current:

32A

Total number of terminals:

5

Total number of potentials:

1

Mounting type:

lever

Material of the connected cable:

copper

Nominal cross-section:

4 mm²

Single-wire cable:

0.2 … 4 mm² / 24 … 12 AWG

Multi-wire cable:

0.2 … 4 mm² / 24 … 12 AWG

Stranded wire:

0.14 … 4 mm² / 24 … 12 AWG

Flammability class according to UL 94:

V2

Fire load:

0 MJ

Dimensions:

29.9 mm x 8.3 mm x 18.6 mm

Weight:

4.048g
